700-800A up to 600VAC StormSwitch – Manual Transfer Switch

Features

  • Quick connect solution for a backup portable generator
  • Mechanically interlocked mechanism prevents cross-connecting power sources
  • Door & dead front panel for safe generator connection and operation
  • Utility and generator disconnects are 3-pole circuit breakers as standard (optional 4-pole breakers or molded case switches available)
  • Type 3R double coated, cold-rolled steel enclosure with gray powdercoat RAL 7035 (stainless steel & additional colors optional)
  • Suitable for Use as Service Equipment (SUSE)
  • Color-coded cam style connectors for easy portable generator connection
  • Direct wire connection available for indoor installations (TempTap Generator Docking Station Required)
  • Handle cover provides security from unauthorized use
  • Wall mountable; leg kits optional
  • U.S. Patent 7462792

Approvals

  • UL/cUL 1008 Listed assembly
  • UL 1691 Listed receptacles
  • UL 489 Listed / CSA certified molded case circuit breaker
  • UL 1087 Listed molded case switch
  • OSHPD seismic certification (OSP)
  • ICC-ES 156 shake-table tested/certified
  • IBC 2015/ASCE 7-10 compliant
