32A 480VAC 4-Gang Rack Mount Assembly

Item No: 2223-31S6
Catalog No: E4-R32-480-30-65SNDPM-SP

Download Spec Sheet

Request More Info

Features

  • UL Listed 4-gang assembly complete with UL Listed safety-interlocked outlets each containing an integral 30A circuit breaker
  • Type 4x enclosure manufactured from 14GA seamwelded stainless steel (powder-coated grey)
  • (4) safety-interlocked ESL outlets #1700-59ANPM factory wired to power distribution block (PDB)
  • UL Listed circuit breaker rated 65kAIC @ 480VAC provides short circuit & overcurrent protection at each outlet
  • Each oultet’s actuator rod allows user to turn on/off and reset tripped breaker
  • PDB accepts incoming cable range of (2) #4AWG – 500kcmil per phase line side
  • Gasketed bolt-on access cover with drip shield

Approvals

  • UL Listed modules and assembly
  • UL 489 Listed / CSA certified molded case circuit breakers

Drawings

If you are a specifying engineer and require a drawing of this item for your current project you can:

Request Drawing Here!
